Adk Draw Wire Absolute Encoder Canopen Ssi High Cost Performance Position Encoder Replace Baumber

Looking for a high-performing position encoder? Our Adk Draw Wire Absolute Encoder Canopen Ssi is the perfect replacement for Baumber at a competitive cost. Visit our factory now!
Request a Quote

PRODUCTS DETAILS

  • Overview
  • Product Parameters
  • Select a draw wire sensor
  • Applications
  • Packaging & Shipping
  • FAQ
Overview

Basic Info.

Operating System
Photoelectric Type
Signal Output
NPN/PNP/Line Driver/Push Pull
Axle Sleeve Type
Shaft
Package
Pg
Installation Form
Axle Sleeve Type
Brand
Gertech
Axonia
Clamping Flange Type
Measurementa Range
3000m
Encoder Interface
Modbus
Accuracy
0.1%
Transport Package
Standard Package
Specification
130x80x110
Trademark
GERTECH
Origin
China
Production Capacity
100000

Packaging & Delivery

Package Size
10.00cm * 20.00cm * 15.00cm
Package Gross Weight
0.500kg

Product Description

GD-WF80 Series

Draw wire encoder with Modbus Absolute encoder



Model No.:GD-WF80-2500-XXXX-XXX

Size:95x95x75mm

Measurement Range:0-2500mm
Encoder Resolution: Max.16bits turns, Max. 16bits per turn; Total Max.:29bits;

Output:NPN PNP Opencollector line Driver, Push Pull

Supply Voltage: 5v,8-29v;




Adk Draw Wire Absolute Encoder Canopen Ssi High Cost Performance Position Encoder Replace Baumber

Product Parameters
Size 95x95x75mm
Measurement Range 0-2500mm
Output format CANopen Interface / NPN PNP Opencollector line Driver, Push Pull
Supply Voltage 24v, 8-29v
Accuracy 0.2%
Linear Tolerance ±0.1%
Power 2w
Wire Rope 0.6mm
Max Pull Power 2.5N
Max. Speed 80mm/s
Working Hours Min50000h
cable Length 1m,2m or as per request

Adk Draw Wire Absolute Encoder Canopen Ssi High Cost Performance Position Encoder Replace Baumber

Select a draw wire sensor

Step 1

Choose the Draw Wire Box according to your measurement Range;

Step 2

Choose the sensor according your preferable output format;

Analog: 0-10v, 4-20mA

Incremental Encoder:NPN, PNP, Line Driver, Push Pull, Voltage Output,

Absolute Encoder: Modbus,CANopen,Profibus,DeviceNet, Profinet, EtherCAT, SSI,BISS,Parallel;

Step 3

Write us a inquiry Letter to describe your demands, we will recommend you with our most cost performance product to satisfy your demands.



Adk Draw Wire Absolute Encoder Canopen Ssi High Cost Performance Position Encoder Replace Baumber
Adk Draw Wire Absolute Encoder Canopen Ssi High Cost Performance Position Encoder Replace Baumber
Adk Draw Wire Absolute Encoder Canopen Ssi High Cost Performance Position Encoder Replace Baumber
Adk Draw Wire Absolute Encoder Canopen Ssi High Cost Performance Position Encoder Replace Baumber
Adk Draw Wire Absolute Encoder Canopen Ssi High Cost Performance Position Encoder Replace Baumber



Applications

Widely applied in the textile machinery, cranes, numerically-controlled machine, automatic, control machine, experimental machine, satellite communication, electric cars, water conservancy project, nuclear power equipment, high-speed rail, wind power, packaging machine, print machine, automatic assembly line and so on.


Packaging & Shipping

The rotary encoder is packed in standard export packaging or as required by buyers
Delivery Time
Shipped within 7 days after full payment by DHL
Adk Draw Wire Absolute Encoder Canopen Ssi High Cost Performance Position Encoder Replace Baumber

FAQ

1) How to select an encoder?
Before ordering encoders, you could clearly know which type of encoder you may need.
There are incremental encoder and absolute encoder, after this, our sale-service department would better work for you.
2) What specifications are requested before order an encoder?
Encoder type----------------solid shaft or hollow shaft encoder
External Diameter----------Min 25mm, MAX 100mm
Shaft Diameter---------------Min shaft 3mm, Max shaft 45mm
Phase & Resolution---------Min 20ppr, MAX 50000ppr
Circuit Output Mode-------you could choose NPN,PNP,Voltage, Push-pull,Line driver, etc
Power Supply Voltage------DC5V-30V
3) How to choose a right encoder by yourself ?
Exact Specification Description
Check The Installation Dimensions
Contact Supplier to get more details
4) How many pieces to start ?
The MOQ is 20pcs .Less quantity is also ok but the freight  is  higher.
5) Why choose "Gertech" Brand Encoder?
All encoders are designed and developed by our own engineer team since year 2004,
and most of the electronic component of encoders are imported from overseas market.
Never let our quality down,because quality is our culture.
6) How long is your lead time?
Short lead time----3 days for samples,7-10days for mass production
7) what is your guarantee policy?
1year warranty and life-long technical support
8)What are the benefit if we become your agency ?
Special prices, Market protection and supporting.
9)What is the process to become Gertech agency?
Please send us enquiry,we will contact you as soon as possible.
10)What is your production capacity?
We produce 5000pcs every week.Now we are building second phrase production line.
