Fast Responding Portable Single Gas Oxygen Meter with Remote Pump

Get fast and accurate oxygen level readings with our portable single gas oxygen meter with remote pump. We are a factory specializing in high-quality gas detection equipment.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
CYH30
Production Name
Portable Oxygen Gas Detector
Transport Package
Kraft Paper Carton
Specification
105*54*32mm/200g
Trademark
SA
Origin
Beijing
HS Code
9027100090
Production Capacity
2000PCS/Month

Product Description

Fast responding portable single gas Oxygen meter with remote pump


FEATURE OF OXYGEN
There are three main risks to gas in confined spaces.
The risk of asphyxia: in confined spaces the air renewal is very rare or even inexistent. The oxygen rate is often below 19,5%, which is the minimal non-hazardous rate. As the confined spaces are poorly ventilated, people working in rejects carbon dioxide (CO2) replacing oxygen.
The risk of hypoxia: confined spaces like tanks, crawl spaces and sewers contain a lot of hazardous gases. These last ones have hypoxic properties, which means that they avoid the oxygen supply that is necessary for the proper functioning of the human body.
The risk of explosion: as oxygen (O2) is a combustion agent, combustible and flammable mixtures may occur in confined spaces.


Portable single gas detector Oxygen (O2)
Before entering a confined space, it is essential to draw gas samples with an O2 gas detector and a specific sampling pump.

Fast responding portable single gas Oxygen meter with remote pump
If the only hazard is the lack of oxygen (O2), an O2 gas detector like our model CYH30 allows real time measures of the oxygen hazardous concentrations.
If other gases are likely to be present, a multigas detector like our model CD4 is highly recommended (combustible gases, O2, CO et H2S).
Fast Responding Portable Single Gas Oxygen Meter with Remote Pump


Display & Specifications
Fast responding portable single gas Oxygen meter with remote pump
-Easy to read LCD display with backlight
-Clear indication of operating status
-95dBA audible alarm
-Striking twin red/blue visual alarm
-Optional vibrating alarm
-High and Low levels of instantaneous alarm
-TWA alarms
-Tough polycarbonate housing
-Full elastomeric overmoulding
-High impact resistance
-IP65 compliant
-Optional 9000 reading data logging storage capacity

Fast Responding Portable Single Gas Oxygen Meter with Remote Pump

* Common ranges: (0.0-30.0)%vol; (0-100)%vol
Series SA-M201  Battery Rechargeable lithium
Sensor type Electrochemical Charging By AC adapter or 5V USB port
Sensor lifetime ≥24 months Charging time 4~5 hours
Respond time 20s (T90) Continuous working time >12h
Alarms LED alarm 20cm Working temperature '-25ºC~ +55ºC
  Buzzer alarm 95dB, 30cm   Short time: -40~+55ºC
  Low power alarm Ex proof  Yes
Alarm threshold Fully adjustable Sampling Natural diffusion
Display Energy saving LED Size & weight 105*54*32mm, 200g
LCD reading Real-time concentration, battery indicator, date IP degree IP54
Fast Responding Portable Single Gas Oxygen Meter with Remote Pump


About Us

Design & Moulding --with 14 years' experience, we make solidest and most practical products

Stricter quality inspection--we persue higher accuracy

Customization--we customize the exact product in your heart

Only focus on gas detector--we think more and deep and offer the best



Company profile:

Beijing Shi'an Tech Instrument Co., Ltd is grown out of Beiijing Dashiweye Technology Co., Ltd, and it's engaged in designing and manufacturing portable gas detectors.

Beijing Dashiweiye Tech, with website of shiantech.en.made-in-china.com, is established in 1997, it focuses on designing, moulding and manufacturing for enclosures of electrical instruments.

Fast Responding Portable Single Gas Oxygen Meter with Remote Pump



Fast responding portable single gas Oxygen meter with remote pump
