Incremental Encoder Trd-2t/2th Series Equivalent Replacement Koyo Sensor

Looking for a reliable replacement for yourIncremental Encoder Trd-2t/2th Series? Look no further than Koyo Sensor. We are a factory specializing in providing high-quality sensors to meet your precise needs.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
ADK-A38L6/K8-IXXXX-XXX
Customized
Customized
Production Capacity
100000

Product Description

OVERRIEWS

Place of  Origin: Weihai, China (Mainland)        Brand Name:IDENCODER
Model Number: ADK-A38L4                                Usage:Position Sensor
Theory: Optical Sensor                                        Output:C,E,P,L
Type: Incremental                                                Shaft:Solid shaft/hollow shaft
Shaft Diameter: Solid Shaft 6mm; Hollow Shaft 8mm;
Outer diameter:38mm
Pulse:10-30000p/r or as requested                       Output signal: A, B Z A- B- Z- phase
Material:metal                                                      Wire outlet: as requested
Quality:1 year                                                       Certification: SGS, ISO9001


Output Circuit

Incremental Encoder Trd-2t/2th Series Equivalent Replacement Koyo Sensor


  Electrical Specifications

  Output circuit Open-collector
outputs
Voltage outputs Push-pull
complementary outputs
Long Driver
  Supply Voltage 5-30v 5-30v 5±0.25  5-30V 5±0.25  5-30V
  Current consumption ≤80mA ≤80mA ≤80MA ≤150mA
  Load current 40mA 40mA 40mA 60mA
  Output high Min Vcc*70% Min Vcc-2.5v Min Vcc-1.5v Min3.4V
  Output Low MAX0.4V MAX0.4V MAX0.8V MAX0.4V
  Rise time Tr MAX1us MAX1us MAX1us MAX200ns
  Fall time Tf MAX1us MAX1us MAX1us MAX200ns
  Highest frequency response 100kHZ 100kHZ 100kHZ 100kHZ

Mechanical Specifications

Max speed r/min Starting torque Axis maximum load Impact Anti-vibration
6000 <0.05nm Radial 50n Axial 50N 50G/11ms 10G 10-200Hz
Moment inertia Work temperature Storage Temperature Protection Degree Weight
4*10.-8kg -25~80ºC -30~85ºC IP51 70g

Incremental Encoder Trd-2t/2th Series Equivalent Replacement Koyo Sensor




Packaging & Delivery

Packaging Details
The rotary encoder is packed in standard export packaging or as required by buyers
Delivery Time
Shipped within 15 days after payment


Company information:

    Weihai Idencoder Electronic Technology Co.,Ltd. are mainly engaged in developing, producing and marketing high-performance industry rotary encoder and provide the electrical automation solutions for our customers.
With the strong R&D team ,our company have gained several proprietary intellectual property rights,seven software copyrights and one patent have been achieved . Three patents for invention are applied on the way.our company cooperates with Harbin Institute of Technology and Beijing University of Aeronautics to research and innovate on the encoder.Now we have successfully developed dozens of  encoders such as,incremental encoder,absolutely encoder,Bus-based encoder and so on.The products of Machinery multi-turns bus-based encoder and Exquisite type true multi-turns Bus-based encoders take the leading position in China domestic market..The PROFINET encoder we are developing now successfully developed has filled a gap in domestic in China.
   Nowadays,Weihai Idencoder Electronic Technology Co.,Ltd. Cooperated with the SIEMENS company and provide our products for the customers all over the world by Siemens Industrial  Ethernet.

Incremental Encoder Trd-2t/2th Series Equivalent Replacement Koyo Sensor

Exhibition:

Incremental Encoder Trd-2t/2th Series Equivalent Replacement Koyo Sensor

Application of rotary encoder

Incremental Encoder Trd-2t/2th Series Equivalent Replacement Koyo Sensor

Packaging and shipping

Incremental Encoder Trd-2t/2th Series Equivalent Replacement Koyo Sensor

FAQ:
1) How to select an encoder?
Before ordering encoders, you could clearly know which type of encoder you may need.
There are incremental encoder and absolute encoder, after this, our sale-service department would better work for you.
2) What specifications are  reque s ted  before order an encoder?
Encoder type----------------solid shaft or hollow shaft encoder
External Diameter----------Min 25mm, MAX 100mm
Shaft Diameter---------------Min shaft 4mm, Max shaft 45mm
Phase & Resolution---------Min 20ppr, MAX 65536ppr
Circuit Output Mode-------you could choose NPN,PNP,Voltage, Push-pull,Line driver, etc
Power Supply Voltage------DC5V-30V
3) How to choose a right encoder by yourself ?
Exact Specification Description
Check The Installation Dimensions
Contact Supplier to get more details
4) How many pieces to start ?
 The MOQ is 20pcs .Less quantity is also ok but the freight  is  higher.
5) Why choose " Idencoder " Brand Encoder ?
All encoders are designed and developed by our own engineer team since year 2004,
and most of the electronic component of encoders are imported from overseas market.
Never let our quality down,because quality is our culture.
6) How long is your lead time?
Short lead time----3 days for samples,7-10days for mass production
7) what is your guarantee policy?
1year warranty and life-long technical support
8)What are the benefit if we become your agency ?
Special prices, Market protection and supporting.
9)What is the process to become IDENCODER agency?
Please send us enquiry,we will contact you as soon as possible.
10)What is your production capacity?
We produce 5000pcs every week.Now we are building second phrase production line.
