IP68 Do Electrode Dissolved Oxygen Sensor for Water Analysis

Get accurate and reliable water analysis with our IP68 Do Electrode Dissolved Oxygen Sensor. As a factory, we ensure high-quality products for your needs.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
OPD790
Portable
Non Portable
Appliance
Food Analysis, Medical Research, Biochemistry, Chemical
Certification
ISO9001, CE
Material
PPS
Protection Level
IP68
Work Pressure
0~3bar
Transport Package
Packaging
Trademark
daruifuno
Origin
China
HS Code
9026809000
Production Capacity
50000 Pieces/Year

Packaging & Delivery

Package Size
23.00cm * 16.00cm * 8.00cm
Package Gross Weight
2.000kg

Product Description



IP68 Do Electrode Dissolved Oxygen Sensor for Water Analysis
Features

Can meet the requirements of fieldwork and short-term or long-term operations.
Without consuming oxygen, especially when the oxygen concentration is very low.
All-in-one package, can be conveniently used with online transmitters, DTU, and portable instruments.
RS485 digital interface, standard Modbus protocol, support access to standard industrial control system.
The protection grade is IP68, can work continuously under water
Internal storage of calibration data, support offline calibration, plug and play on site.


Specification

Product Model OPD790
Measuring range Oxygen content: 0.00~20.00 mg/L
saturation: 0~200%
Resolution 0.01mg/L  1%
Accuracy ±0.1 mg/L
Response Time 90% of the value in less than 30 seconds
Compensation Automatic temperature, salinity and pressure compensation
Calibration Method Zero and span calibration
Work Pressure 0~3Bar
Operating Temperature 0.0~50.0ºC
Material PPS
Dimensions Diameter: 35mm, total length: 260mm
Installation Size One inch 1"NPT at the beginning and end of the installation thread
Protection level IP68
Weight 170g
