M500t Benchtop Multi Parameter Aquaculture Water Quality Analyzer pH ORP TDS Dissolved Oxygen Turbidity Meter

Introducing the M500t Benchtop Multi Parameter Aquaculture Water Quality Analyzer, perfect for monitoring pH, ORP, TDS, dissolved oxygen, and turbidity. Quality assured by our factory.
Request a Quote

PRODUCTS DETAILS

  • Overview
  • Our Advantages
  • Packaging & Shipping
  • Company Profile
Overview

Basic Info.

Model NO.
M500T
Portable
Portable
Appliance
Biochemistry, Water Quality Analysis
Certification
ISO9001, CE
Model Number
M500t
pH Range
-2.000 to 20.000 pH
pH Accuracy
±0.002
Mv/ORP Range
-2000.00 to 2000.00 Mv
Conductivity Range
0.000 μs/Cm to 2000 Ms/Cm
Resistivity Range
5.00 Ω Cm~100.0 MΩ Cm
TDS Range
0.000~1000 Ppt
Salinity Range
0.0~80.0 Ppt
Dissolved Oxygen Range
0.00 to 99.99 Ppm
Temperature Range
-10 to 135 ºC, 14 to 275 ºF
Transport Package
Package for Exporting
Specification
37X35X33 cm
Trademark
SKZ
Origin
China
Production Capacity
50000PCS/Year

Packaging & Delivery

Package Size
37.00cm * 35.00cm * 33.00cm
Package Gross Weight
5.500kg
Lead Time
15 days (1 - 1 Pieces)
20 days (2 - 5 Pieces)
To be negotiated ( > 5 Pieces)

Product Description

M500t Benchtop Multi Parameter Aquaculture Water Quality Analyzer pH ORP TDS Dissolved Oxygen Turbidity Meter
M500T Benchtop Multi Parameter Aquaculture Water Quality Analyzer pH ORP TDS Dissolved Oxygen Turbidity Meter
GENERAL FEATURES 1. Color High contrast LCD touchscreen, 7.0 inches. 2. Intelligent operation system provides features including user management, calibration management, method management, data management and etc. 3. Multi-reading feature allows auto-read, timed-read and continuous-read. 4. Automatic/Manual temperature compensation ensures accurate results. 5. Data Storage 1000 sets for each parameter (GLP-compliant). 6. Data analysis feature helps user review, compare and recalculate results. 7. Support for USB or RS-232 communication. 8. Reset feature automatically resumes all settings back to factory default options. 9. IP54 waterproof. pH 1. 1-6 points calibration with Standard Recognition. 2. Selectable pH buffer groups, including DIN, NIST, USA, MERK, JIS, GB. 3. Support for pH standard group customization. 4. Automatic electrode diagnosis with pH slope and offset display. Ion 1. 1-6 points calibration 2. Selectable measurement unit, including μg/L, mg/L, g/L, mmol/L, pX, ppm, ppb, etc. 3. Multi-measurement modes are supported, including Direct Reading mode, Standard Addition mode, Sample Addition mode and GRAN mode. 4. Over 10 methods are built-in, including F-, Cl-, Br-, I-, NO3-, BF4-, NH4+, K+, Na+, Ca2+, Cu2+, Pb2+, Ag+ and etc., user-defined method is supported. Conductivity 1. 1-5 points calibration with Standard Recognition. 2. Settable parameters, including cell constant, reference temperature (5/10/15/18/20/25°C), temperature compensation coefficient and TDS factor. 3. Temperature compensation type (none, linear, pure water). DO 1. Support for air-saturated water or zero oxygen calibration. 2. Auto barometric pressure compensation. 3. Manual Salinity Factor Correction. 4. Selectable pressure unit, including kPa, mbar, Torr, Atm. Includes 1. E-301-QC 3 in 1 pH composite electrode 2. DJS-1VTC EC electrode 3. DO-958-Q polarographic DO electrode 4. NIST pH standard solution(4.01, 7.00, 10.01) , 50ml/vial (1413μS/cm EC standard solution, 50ml, 1 vial) 5. REX-6 electrode stand 6. Touch pen
Specification
Model
M500T
Parameters
pH/EC/ISE/DO/Temp. (mV/ORP/pX/Resistivity/TDS/Sal./DO Saturation)
pH
Range
-2.000 to 20.000 pH
Resolution
0.1, 0.01, 0.001pH
Accuracy
±0.002 pH
Calibration Points
Up to 6
Standard Customization
Yes
Calibration Reminder
Yes
Standard Recognition
NIST, GB, DIN, USA, MERK, JIS buffers
Slope Limit
Yes
mV/ORP
Range
-2000.00 to 2000.00 mV
Resolution
0.1, 0.01 mV
Accuracy
±0.1 mV or ±0.03% of
reading whichever is greater
EH ORP Mode
Yes
ORP Calibration Points
1 custom point (relative mV)
pX
Range
-2.000 to 20.000 pX
Resolution
0.1, 0.01, 0.001 pX
Accuracy
±0.002 pX
Calibration Points
Up to 6
ISE
Range
1.000e-9 to 9.999e+9
Units
mol/L, mmol/L, g/L, mg/L, μg/L, ppm, ppb
Resolution
Up to 4 significant digits
Accuracy
±0.3%
Calibration Points
Up to 6
Conductivity
Range
0.000 μS/cm to 2000 mS/cm
Resolution
0.001 μS/cm minimum,
various with range selection
Accuracy
±0.5% FS
Reference Temperature
5, 10, 15, 18, 20, 25 ºC
Calibration Points
Up to 5
Calibration Reminder
Yes
Standard Recognition
10 μS/cm, 84 μS/cm, 500 μS/cm, 1413 μS/cm, 12.88 mS/cm; 146.5μS/cm, 1408μS/cm, 12.85mS/cm, 111.3mS/cm
Resistivity
Range
5.00 Ω·cm~100.0 MΩ·cm
Resolution
0.01 Ω·cm minimum
Accuracy
±0.5% FS
TDS
Range
0.000~1000 ppt
Resolution
0.001 ppm minimum, changed with range
Accuracy
±0.5% FS
Salinity
Type
NaCl
Range
0.0~80.0 ppt
Resolution
0.1ppt
Accuracy
±1ppt
Dissolved
Oxygen Concentration - Polarographic
Range
0.00 to 99.99 ppm
Resolution
0.01 ppm
Accuracy
±0.10ppm,(0.00~50.00)ppm
±0.50ppm,(50.0~99.99)ppm
Calibration Reminder
Yes
Calibration Points
Air-saturated water or zero point
Barometric Compensation
Yes
Manual Salinity Factor Correction
Yes
% Saturation -
Polarographic
Range
(0.0 to 600)%
Resolution
0.10%
Accuracy
±2.0%
Temperature
Range
-10 to 135 ºC, 14 to 275 ºF
Unit
ºC, ºF
Resolution
0.1
Accuracy
±0.1ºC
Measurement
Reading Mode
Auto Read (Fast, Medium, Slow), Timed, Continuous
Reading Prompts
Reading, Stable, Locked
Temp. Compensation
ATC, MTC
Data management
Data Storage
1000 Groups
GLP Features
Yes
Log Management
Yes
Inputs
pH Electrode
BNC(Q9)
DO with Temp. Probe
4-pin aviation connector
Conductivity with Temp. Probe
5-pin aviation connector
Outputs
USB
USB 2.0 flash memory device, PC, scanner,
RS 232
printer, auto-sampler
Display options
Backlight
Yes
Auto Shutdown
1~60 min, off
IP Rating
IP54
Date and Time
Yes
General
Power
AC Adapter, 100-240V AC input, DC24V output
Dimensions
220×195×68 mm
Weight
950g (2.09 lb)
Dimensions (Carton)
370×305×330 mm
Weight (Gross)
5.5 kg
