100% New Smallest and Exquisite Handheld 3.5inches Portable Vital Sign Monitor Patient Monitor with SpO2, Temp, NIBP 3 Parameters

Introducing our 100% new smallest and exquisite handheld 3.5 inches portable vital sign monitor. Factory-direct with SpO2, Temp, NIBP 3 parameters.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Specification
3.5inch
Trademark
Ronseda
Origin
China

Product Description

100% New Smallest and Exquisite Handheld 3.5inches Portable Vital Sign Monitor Patient Monitor with SpO2, Temp, NIBP 3 Parameters100% New Smallest and Exquisite Handheld 3.5inches Portable Vital Sign Monitor Patient Monitor with SpO2, Temp, NIBP 3 Parameters100% New Smallest and Exquisite Handheld 3.5inches Portable Vital Sign Monitor Patient Monitor with SpO2, Temp, NIBP 3 Parameters
Features:
1.The smallest and exquisite handheld vital sign monitor in the worldwide
2.Accurate measurement in 0.05% Low perfusion Index,the world leading production in the movement environment
3.Provide the parameter of PI( Perfusion Index 0.05%-20%)
4.Accurate measurement in all kind of extreme environment measurement such as neonatal and shock patients
5.NIBP adopt SAWAA(Self-Adaptive-Waveform-Amplitude -Adjust)algorithm and SAFD(Self-Adaptive-Fast-Deflation)algorithm
6.Easy operation by 3.5 inch color TFT
7.Multiple vital signs measurement parameters for collocation optional
VT200A:NIBP,Spo2,Temp
VT200B:NIBP,Temp
VT200C:Spo2,Temp
8.Up to 100 users ID switch
9.Two measurements mode:Spot,Monitoring
10.Data storage capabilities, support for historical data view and trend chart back for checking
11.In monitoring mode, can continuously record 48 hours of measurement data
12.In spot mode,100 users ID, each user can store 200sets data
13.Support audio and visual alarm,support to set alarm upper and lower limit values
14.Lithium ion battery power supply

Specifications:
Display:3.5 inch color TFT Resolution:320X480
Indicator: Alarm indicator, Power indicator
Trace: 1 plethysmogram waveform
Alarm: Probe off, low power
Modes: Visual and Audio
Application: Neonatal, pediatric and adult patients

NIBP
The wider NIBP measurement range

Adult
PED
NEO
SYS
40~270mmHg
40~200mmHg
40~135mmHg
MEAN
20~230mmHg
20~165mmHg
20~105mmHg
DIA
10~210mmHg
10~150mmHg
10~95mmHg
Pulse rate range:40~240bpm
NIBP measurement accuracy:±3mmHg
Pulse rate measurement accuracy:<=2% (>=100 BPM) or 2 beats/min (<100 BPM)
Independent software protection  pressure
Adult:300mmHg             PED:240mmHg               NEO:150mmHg
Independent hardware protection  pressure
Adult:320-330mmHg         PED:265-275mmHg          NEO:160-165mmHg

Oxygen Saturation (%SpO2)
Measurement range:
measure range
SpO2:0-100%
PR:0-300bpm
Perfusion index:0.05%-20%
Accuracy range:
SpO2 saturation: 70-100%
Pulse rate: 20-254BPM
Perfusion Index:0.025%-20%
Measurement accuracy
SpO2:
Adult (including pediatric ) + 2digit(70-100%)       not defined (<70%)
Neonate  + 3 digits     not defined(<70%)
On motion condition + 3digit
PR:
Adult (including pediatric) + 3digits
Neonate  + 3 digits
On motion condition + 3digit
Perfusion Index:
0.05%-20%
Resolution
SpO2 saturation: 1%
Pulse rate: 1BPM

Temperature
Measurement range: 25 -45 degree
Resolution:0.1 degree
Accuracy:0.1 degree
Power Type: Lithium ion battery
Operation time: 8 hours for normal operation
Temperature:
Operating: 0-45 degree
Starage/ Transportation: -20-65 degree
Humidity:
Operating: 15% to 90% noncondensing
Storage:  0% to 95% noncondensing
Operating Altitude: Up to 5000 meters

Size
Dimension 146mmX67mmX30mm
Weight 250g
100% New Smallest and Exquisite Handheld 3.5inches Portable Vital Sign Monitor Patient Monitor with SpO2, Temp, NIBP 3 Parameters100% New Smallest and Exquisite Handheld 3.5inches Portable Vital Sign Monitor Patient Monitor with SpO2, Temp, NIBP 3 Parameters100% New Smallest and Exquisite Handheld 3.5inches Portable Vital Sign Monitor Patient Monitor with SpO2, Temp, NIBP 3 Parameters100% New Smallest and Exquisite Handheld 3.5inches Portable Vital Sign Monitor Patient Monitor with SpO2, Temp, NIBP 3 Parameters100% New Smallest and Exquisite Handheld 3.5inches Portable Vital Sign Monitor Patient Monitor with SpO2, Temp, NIBP 3 Parameters100% New Smallest and Exquisite Handheld 3.5inches Portable Vital Sign Monitor Patient Monitor with SpO2, Temp, NIBP 3 Parameters100% New Smallest and Exquisite Handheld 3.5inches Portable Vital Sign Monitor Patient Monitor with SpO2, Temp, NIBP 3 Parameters
100% New Smallest and Exquisite Handheld 3.5inches Portable Vital Sign Monitor Patient Monitor with SpO2, Temp, NIBP 3 Parameters
