400s Ton High Speed Stamping Closed Double-Crank Punching Power Press Machine

Get the best 400s Ton High Speed Stamping Closed Double-Crank Punching Power Press Machine from our factory. High-quality and efficient solutions for your punching needs.
Request a Quote

PRODUCTS DETAILS

Basic Info.

Model NO.
APE-400S
Automatic Grade
Automatic
Power Source
Pneumatic
Precision
High Precision
Certification
CE, ISO 9001
Condition
New
Capacity
400 Metric Tons
Stroke
300 mm
Die Height
550 mm
RAM Adjustment
120 mm
RAM
2300mm X 1000mm
Bed
2500mm X 1000mm
Motor Power
37kw X 4
Air Pressure
0.6MPa
Stroke Per Minute
20- 30 S. P. M
Slide Adjust Device
2X4
Transport Package
Metal Pallet with Plastic Fim
Trademark
EDPS
Origin
China

Product Description


With high rigidity design in machine frame, the machine body is welded of quality steel sheet adn treated by tension elimination, improve stability and reliability of the mechanical precision.
400s Ton High Speed Stamping Closed Double-Crank Punching Power Press Machine
400s Ton High Speed Stamping Closed Double-Crank Punching Power Press Machine


Performance Feature

1.Hight steel performance frame,large center span of the conneeting rod,strong anti partial load,optimize design.
2.In order to guarantee relative stationarity of machine operation,it is necessary to balance two balancers.
3. Moulding-adjustment precision is as high as 0.1mm, safe, speedy,and reliable.
4. Through hard oxidation and grinding, such parts as bent axles, gear sets,and connecting rods possess higher combination property and tolerance.
5.Adopt highly sensitive and reliable clutch/brake and internationally top duplex magnetic valve, as well as overload protection devices, to guarantee precision and safety
   for operation and stop of press rams.
6.Machine's structural design shall be reasonable, for the convenience of realizing automatic production, reducing cost, and improving efficiency.
7.Possess advanced design concepts, low noise, low consumption, and energy saving.
400s Ton High Speed Stamping Closed Double-Crank Punching Power Press Machine
400s Ton High Speed Stamping Closed Double-Crank Punching Power Press Machine


Technical Specification

400s Ton High Speed Stamping Closed Double-Crank Punching Power Press Machine

400s Ton High Speed Stamping Closed Double-Crank Punching Power Press Machine
400s Ton High Speed Stamping Closed Double-Crank Punching Power Press Machine




Standard configuration

400s Ton High Speed Stamping Closed Double-Crank Punching Power Press Machine
>Dry clutch brake

> standard operating system of yiduan

>Choice/cutting/inch/safejourney/continuation of operating mode

>Oil pressure overload protection device

> Over-run safety device

> Duplex magnetic valve

>Misfeed detection consent

> Electric slider adjusting device

>Digital moulding-height indicator
(unit: 0.1 mm)

>Auto grease pump device

>Accumulative counter (6 digits)

>Pre-determined counter(6 digits)
400s Ton High Speed Stamping Closed Double-Crank Punching Power Press Machine
400s Ton High Speed Stamping Closed Double-Crank Punching Power Press Machine
> Maintenance counter (6 digits)

> Life counter (6 digits)

>Electronic rotatry cam switch(6 connections)

>Air-blast device 1/2" one circuit

>Air source connector 1/2" two circuit

> Error inspection socket

> Power socket

Optional Configuration

> Wet clutch brake
> Die cushion device
> Vs variable-speed motor
> Touch-screen device
> Photo-electric safety device
> Upper slider feeding device
> Main motor inversion device
> Foot switch

> Safety dog and safety latch
> T-type two-hand button operating floon
> Inspection variable-connection magnetic valve
> Anti-vibration mechanical foot
> Rapid tooling exchange
> Upper die clamper
> Lower die clamper

> Die lifter
> Mould-shift arm
> Basic bolt and soleplate
> Automatic feeder device
> Three-in-one NC straightening feeder
> NC Roll feeder
> Three-in-one feeder and straightening machine
> Leveller
400s Ton High Speed Stamping Closed Double-Crank Punching Power Press Machine

Transport And Pack

We are currently reviewing our product packaging from the angles of waste-reduction and resource-saving. We are also working on improving transportation efficiency from the design phase of product development.
All the spare parts of the machine were covered by the some soft materials mainly using plastic film.
Our wooden pallet is after fumigation treatment. Needn't timber inspection, saving shipping time.
Our metal pallet is special designed and paint grease at the bottom so that we can load easily.
